Description
Part Number
5901934
Engine Brand
Yanmar™ Diesel
Engine Power Rating (HP) *
24
Displacement (cc)
904
PTO
Electric
Cylinders
3
Starter
Electric
Fuel Tank Capacity (litres)
41.6
Cutting Width in(cm)
61 (155)
Cutting Height in(cm)
1.75 – 5 (45 – 129)
Spindles
Cast-iron greaseable
Deck Construction
iCD™ Cutting System
Suspension
Independent front control arms with large adjustable coil-over-shocks and a rear swing-arm with large adjustable coil-over-shocks
Transmission
Dual commercial Hydro-Gear® ZT-4400™ transaxles with 8.3″ cooling fans
Drive Axles (in)
1.375
Caster Tyres (in)
13 x 6.5 – 6
Drive Tyres (in)
24 x 12 – 12
Ground Speed-Fwd (kph)
0 – 16
Ground Speed-Rev (kph)
0 – 8.1
Overall Length (mm)
2191
Overall Width (mm) Deflector Down / Up
1950 / 1613
Dry Weight (kg)
729
Seat Package
Premium high-back with arm rests
Instrumentation
Dual-function hour meter, fuel level gauge in each tank
ROPS
180° foldable
Controls / Safety Group
Seat activated engine kill, clutch safety switch, neutral and parking brake safety circuit, adjustable twin steering controls
Parking Brake / Safety Circuit
Hand-operated internal transaxle brake
Warranty (Engine) †
2-Year limited manufacturer’s warranty
Warranty (Balance of Machine) †
4-Year limited warranty (48 months) or 500 hours, whichever occurs first. Unlimited hours during the first 2 years (24 months). Coil-over-shocks and all suspension related components are covered for 5 years (60 months) unlimited hours. Coverage on other components varies, please see operator’s manual for complete details.
